Honda CB125R – 23YM

6,099

This early-entry motorcycle – a tenacious sibling of the CB1000R – really makes a statement with its alloy radiator shroud, hugging sump guard and all-black engine. A new tubular frame and tough-looking 41mm upside-down forks are topped with a state-of-the-art LCD instrument panel; headlight, taillight and indicators are all LED for extra brightness.

Description

Engine

Bore × Stroke (mm) 58mm x 47.2mm
Carburation PGM-FI electronic fuel injection
Compression Ratio 11.0:1
C02 Emissions (g/km) 48
Engine Displacement (cc) 125cc
Engine Type (cm³) Liquid-cooled 4-stroke 2-valve SOHC single cylinder
Max. Power Output 9.8kw/10000rpm
Max. Torque 10Nm/8000rpm
Oil Capacity (Litres) 1.3L
Starter Electric

Wheels

ABS System Front & rear independent ABS with IMU
Suspension Front 41mm telescopic inverted fork
Suspension Rear Single-damper
Tyre Size Front 110/70R17M/C 54H
Tyre Size Rear 150/60R17M/C 66H
Wheels Front 17M/C x MT3.00
Wheels Back 17M/C x MT4.00

Dimensions and Weights

Battery Capacity (VAh) YTZ6V 12V 5Ah MF
Caster Angle 24.2°
Dimensions (L×W×H) (mm) 2015mm x 820mm x 1055mm
Frame type Inner Pivot Diamond Frame
Fuel Tank Capacity (Litres) 10.1L
Fuel Consumption 48.4km/L (WMTC Mode)
Ground Clearance (mm) 140mm
Kerb Weight (kg) 126kg
Seat Height (mm) 816mm
Trail (mm) 90.2mm
Wheelbase (mm) 1345mm

Transmission

Clutch Wet, multiplate with coil springs
Final Drive O-ring sealed chain
Gearbox 6-speed

Instruments and Electrics

Headlights Lo:13W Hi: 8.8W (LED)
Instruments LCD Display
Tail Light Stop: 2.5W Tail: 0.4W (LED)
