€23,299
KTM brought out the big guns when considering the most hardcore, long distance adventurers. They packed 1301 cc into the world’s most advanced travel enduro chassis. Ready to take on any terrain, this mile-munching weapon is the ultimate offroad travel enduro for exploring the trail less traveled and beyond.
Description
TECHNICAL DETAILS
ENGINE
- TRANSMISSION6-speed
- COOLINGLiquid cooled
- POWER IN KW118 kW
- STARTERElectric starter
- STROKE71 mm
- BORE108 mm
- CLUTCHPASC (TM) slipper clutch, hydraulically actuated
- DISPLACEMENT1301 cm³
- EMSKeihin EMS with RBW and cruise control, double ignition
- DESIGN2-cylinder, 4-stroke, V 75°
- LUBRICATIONForced oil lubrication with 3 oil pumps
CHASSIS
- ABSBosch 10.3ME Combined-ABS (incl. Cornering-ABS and offroad mode)
- FRONT BRAKE DISC DIAMETER320 mm
- REAR BRAKE DISC DIAMETER267 mm
- CHAIN525 X-Ring
- FRAME DESIGNChrome-moly tubular space frame, powder-coated
- FRONT SUSPENSIONWP XPLOR-USD, Ø 48 mm
- REAR SUSPENSIONWP Xplor PDS shock absorber
- STEERING HEAD ANGLE64.7 °
