€19,299 (CRF1100A3 E/S)
€20,799 (CRF1100D3 DCT E/S)
Description
Engine
| Bore × Stroke (mm) | 92.0mm x 81.5mm |
| Carburation | PGM-FI |
| Compression Ratio | 10.5:1 |
| Engine Displacement (cc) | 1084 cm3 |
| Engine Type | Liquid-cooled 4-stroke 8-valve Parallel Twin with 270° crank and uni-cam |
| Max. Power Output | 75.0kW/7500min |
| Max. Torque | 112Nm/5,500rpm |
| Starter | Electric |
| Throttle Bore | 46mm |
| C02 Emissions (g/km) | 114g/km |
| Oil Capacity (Litres) | 4.8 |
Wheels
| Brakes Front | 310mm dual wave floating hydraulic disc with aluminium hub and radial fit 4-piston calipers and sintered metal pads |
| Brakes Rear | 256mm wave hydraulic disc with 2-piston caliper and sintered metal pads. 2-Channel with rear ABS off mode. |
| Suspension Front | Showa 45mm cartridge-type inverted telescopic fork with dial-style preload adjuster and DF adjustments, 230mm stroke. |
| Suspension Rear | SHOWA Telescopic inverted fork with an inner tube diameter of 45mm, and an Electric controlled unit (SHOWA EERA) with compression and rebound dumping adjustments, 210mm stroke |
| Tyre Size Front | 110/80-R19M/C 59V (Tubeless) |
| Tyre Size Rear | 150/70-R18M/C 70H (Tubeless) |
| Tyres Rear | Bridgestone BATTLAX ADVENTURECROSS TOURER AX41T Metzeler KAROO STREET |
| Wheels Front | 19M/C x MT2.50 Wire spoke with aluminium rim |
| Wheels Rear | 18M/C x MT4.00 Wire spoke with aluminium rim |
Dimensions and Weights
| Battery Capacity (VAh) | 12V-6Ah Li-ion BATTERY |
| Caster Angle | 27.5° |
| Dimensions (L×W×H) (mm) | 2,305mm X 960mm X 1,475mm |
| Frame type | SemiDouble Cradle |
| Fuel Tank Capacity (Litres) | 24.8L |
| Fuel Consumption | 20.5km/l |
| Ground Clearance (mm) | 220mm |
| Kerb Weight (kg) | 243 |
| Seat Height (mm) | 835/855mm (Low Seat option 795mm) |
| Trail (mm) | 106 mm |
| Wheelbase (mm) | 1550mm |
| Turning Radius | 2.6 |
Transmission
| Clutch | Wet, Multiplate with coil springs, Aluminium Cam Assist and Slipper clutch |
| Clutch Operation | Cable |
| Final Drive | O-ring sealed chain |
| Gearbox | 6-speed |
| Transmission Type | Manual Clutch Transmission |
| Quick Shifter | Optional Accessory |
Instruments and Electrics
| 12v Socket | Yes |
| Headlights | LED |
| Ignition System | Electronic, digital transistor |
| Instruments | LCD METER 6.5inch TFT Touch Panel Multi information display |
| Tail Light | LED |
| Daytime Running Lights | Yes |
| Cornering Lights | Yes |
| Connectivity | Bluetooth audio and Apple CarPlay/Android Auto (wired) |
| USB Socket | Yes (USB Type A, 1.5A) |
| Self Cancelling Indicators | Yes |
| Cruise Control | Yes |
| Emergency Stop Signal | Yes |
| Security | Immobiliser |
